Outdoor LED Video Wall

• Application Areas
• Outdoor Billboards, Stadium Perimeters, Shopping Malls, Transit Hubs

• Contrast Ratio
• 3000:1

• Control System
• Synchronous / Asynchronous Control System Supported

• Features
• High Brightness, Weatherproof, Energy Saving, Wide Viewing Angle

• Installation Type
• Wall Mounted / Hanging / Stacking

• LED Type
• SMD (3-in-1)

• Material
• Die-Cast Aluminum or Steel Cabinet

• Panel Size
• 1000mm x 1000mm / 960mm x 960mm / 640mm x 640mm (common sizes)

• Pixel Pitch
• P4, P6, P8, P10 mm (varies by model)

• Power Consumption
• Max: 750W/m2, Avg: 300W/m2 Watt (W)

• Usage
• Outdoor Advertising, Sports Stadiums, Events, Public Displays

• View Angle
• Horizontal: 140, Vertical: 120

• Voltage
• AC 110~240V, 50/60Hz Volt (v)

• Weight
• Approx. 28-35 kg per panel (varies by model) Kilograms (kg)

• Application Areas
• Outdoor Advertising, Live Events, Retail Exteriors, Public Spaces

• Contrast Ratio
• 10,000:1

• Display Type
• High-End Outdoor LED Video Wall

• Features
• Ultra-High Brightness, IP65 Rated, Front & Rear Maintenance, Wide Viewing Angle

• Installation Type
• Outdoor Fixed Installation

• LED Type
• SMD1921

• Material
• Die-Cast Cabinet

• Operating Temperature
• -20 C to +60 C Celsius (oC)

• Panel Size
• 1000 1000 mm

• Pixel Pitch
• P3.91

• Power Consumption
• Average 260 W/m ; Maximum 780 W/m Watt (W)

• Power Rating
• Maximum 780 W/m

• Rated Voltage
• AC 110 240V Volt (V)

• Usage
• Outdoor

• Usage & Applications
• Outdoor Advertising, Live Events, Retail Exteriors, Public Spaces

• View Angle
• 140 Horizontal / 160 Vertical

• Voltage
• AC 110 240V Volt (v)

• Warranty
• 1 Years

• Weight
• 22.5 kg Kilograms (kg)
